JST, EL Male Connector Housing, 12 Way, 3 Row
Tehnička dokumentacija
Tehnički podaci
Proizvođač
JSTNumber Of Contacts
12
Number Of Rows
3
Gender
Male
Series
EL
For Use With
4.5 mm Disconnectable Crimp Wire-to-Wire Connector
Length
19.3mm
Housing Material
Nylon
Zemlja podrijetla
Japan
Detalji o proizvodu
JST EL Connector Housing
The EL range of connector housings from JST have a 4.5mm pitch. The contacts are easily inserted and installed into the connector housings and due to the housings wide surface area, a safe and smooth connection can be maintained when mating, even if mechanical distortion occurs.
Standards
Compliant with UL, CSA, TUV
Electrical Appliance and Material Safety Act (spatial / creepage distance for insulating material)
Single-digit 7-segment Blue LED Displays
Single-digit 7-segment Blue LED displays from Broadcom (Avago Technologies).
Zamisliti. Stvoriti. Surađivati
PRIDRUŽITE SE BESPLATNO
Bez skrivenih naknada!
- Preuzmite i koristite naš softver DesignSpark za svoje PCB i 3D mehaničke dizajne
- Pregledajte i doprinesite sadržaju internet stranice i foruma
- Preuzmite 3D modele, sheme i otiske s više od milijun proizvoda
€ 10,80
€ 1,08 komadno (u pakiranju od 10) (bez PDV-a)
€ 13,50
€ 1,35 komadno (u pakiranju od 10) (s PDV-om)
10
€ 10,80
€ 1,08 komadno (u pakiranju od 10) (bez PDV-a)
€ 13,50
€ 1,35 komadno (u pakiranju od 10) (s PDV-om)
Informacije o stanju skladišta trenutno nisu dostupne.
10
Informacije o stanju skladišta trenutno nisu dostupne.
| količina | jedinična cijena | Po pakiranje |
|---|---|---|
| 10 - 90 | € 1,08 | € 10,80 |
| 100 - 490 | € 1,06 | € 10,60 |
| 500 - 2490 | € 0,96 | € 9,60 |
| 2500 - 4990 | € 0,89 | € 8,90 |
| 5000+ | € 0,87 | € 8,70 |
