Panasonic, ETQP5M, PCC-M Wire-wound SMD Inductor with a Metal Composite Core, 4.7 μH ±20% Wire-Wound 13.1A Idc
Tehnička dokumentacija
Tehnički podaci
Proizvođač
PanasonicInductance
4.7 μH
Maximum dc Current
13.1A
Package/Case
PCC-M
Length
10.7mm
Depth
10mm
Automotive Standard
AEC-Q200
Height
5.4mm
Dimensions
10.7 x 10 x 5.4mm
Tolerance
±20%
Maximum DC Resistance
11.3mΩ
Series
ETQP5M
Core Material
Metal Composite
Maximum Self Resonant Frequency
100kHz
Maximum Operating Temperature
+150°C
Moulded
Yes
Minimum Operating Temperature
-40°C
Inductor Construction
Wire-Wound
Zemlja podrijetla
Indonesia
Detalji o proizvodu
ETQP5M Series Magnetically Shielded Wire Wound Chokes
Panasonic ECQP5M choke coils provide a high reliability solution. Featuring heat resistance up to +150°C, the use of ferrous alloy magnetic material provides excellent inductance stability. New metal composite core technology creates low buzz noise, and the integral construction enables high vibration resistance.
Panasonic Non Standard SMT Inductors (Chokes)
Zamisliti. Stvoriti. Surađivati
PRIDRUŽITE SE BESPLATNO
Bez skrivenih naknada!
- Preuzmite i koristite naš softver DesignSpark za svoje PCB i 3D mehaničke dizajne
- Pregledajte i doprinesite sadržaju internet stranice i foruma
- Preuzmite 3D modele, sheme i otiske s više od milijun proizvoda
€ 800,00
€ 0,80 Each (On a Reel of 1000) (bez PDV-a)
€ 1.000,00
€ 1,00 Each (On a Reel of 1000) (s PDV-om)
1000
€ 800,00
€ 0,80 Each (On a Reel of 1000) (bez PDV-a)
€ 1.000,00
€ 1,00 Each (On a Reel of 1000) (s PDV-om)
Informacije o stanju skladišta trenutno nisu dostupne.
1000
Informacije o stanju skladišta trenutno nisu dostupne.
