Tehnička dokumentacija
Tehnički podaci
Proizvođač
SiemensMaximum Load Current
30A
Product Type
Solid State Relay
Mount Type
DIN Rail
Maximum Load Voltage
230V
Minimum Load Voltage
24V
Maximum Control Voltage
24V dc
Minimum Control Voltage
15V dc
Series
3RF2
Terminal Type
Screw
IP Rating
IP20
Contact Configuration
SPST
Minimum Operating Temperature
-25°C
Switching Function
Zero Cross Switching
Maximum Operating Temperature
60°C
Standards/Approvals
UR, EAC, CSA
Width
45mm
Height
57.6mm
Length
45mm
Off State Leakage Current
10mA
Zemlja podrijetla
Germany
Detalji o proizvodu
Temperature can affect current rating; please consult the data sheet for potential derating.
Zamisliti. Stvoriti. Surađivati
PRIDRUŽITE SE BESPLATNO
Bez skrivenih naknada!
Informacije o stanju skladišta trenutno nisu dostupne.
€ 61,74
€ 61,74 komadno (bez PDV-a)
1
€ 61,74
€ 61,74 komadno (bez PDV-a)
Informacije o stanju skladišta trenutno nisu dostupne.
1
Zamisliti. Stvoriti. Surađivati
PRIDRUŽITE SE BESPLATNO
Bez skrivenih naknada!
Tehnička dokumentacija
Tehnički podaci
Proizvođač
SiemensMaximum Load Current
30A
Product Type
Solid State Relay
Mount Type
DIN Rail
Maximum Load Voltage
230V
Minimum Load Voltage
24V
Maximum Control Voltage
24V dc
Minimum Control Voltage
15V dc
Series
3RF2
Terminal Type
Screw
IP Rating
IP20
Contact Configuration
SPST
Minimum Operating Temperature
-25°C
Switching Function
Zero Cross Switching
Maximum Operating Temperature
60°C
Standards/Approvals
UR, EAC, CSA
Width
45mm
Height
57.6mm
Length
45mm
Off State Leakage Current
10mA
Zemlja podrijetla
Germany
Detalji o proizvodu
Temperature can affect current rating; please consult the data sheet for potential derating.
