Tehnička dokumentacija
Tehnički podaci
Proizvođač
STMicroelectronicsProduct Type
Diode
Mount Type
Through Hole
Package Type
TO-247
Maximum Continuous Forward Current If
15A
Peak Reverse Repetitive Voltage Vrrm
200V
Diode Configuration
Common Cathode
Series
STTH3002C
Rectifier Type
Switching
Pin Count
3
Peak Reverse Current Ir
20μA
Maximum Forward Voltage Vf
1.18V
Minimum Operating Temperature
-65°C
Peak Non-Repetitive Forward Surge Current Ifsm
180A
Peak Reverse Recovery Time trr
22ns
Maximum Operating Temperature
175°C
Length
15.75mm
Height
20.15mm
Standards/Approvals
RoHS
Automotive Standard
No
Detalji o proizvodu
Zamisliti. Stvoriti. Surađivati
PRIDRUŽITE SE BESPLATNO
Bez skrivenih naknada!
Informacije o stanju skladišta trenutno nisu dostupne.
€ 17,25
€ 3,45 Each (Supplied in a Tube) (bez PDV-a)
€ 21,56
€ 4,31 Each (Supplied in a Tube) (s PDV-om)
Proizvodno pakiranje (cijev)
5
€ 17,25
€ 3,45 Each (Supplied in a Tube) (bez PDV-a)
€ 21,56
€ 4,31 Each (Supplied in a Tube) (s PDV-om)
Informacije o stanju skladišta trenutno nisu dostupne.
Proizvodno pakiranje (cijev)
5
| količina | jedinična cijena |
|---|---|
| 5 - 9 | € 3,45 |
| 10 - 24 | € 3,20 |
| 25+ | € 3,00 |
