Tehnička dokumentacija
Tehnički podaci
Brand
CrydomMaximum Load Current
5A
Product Type
Solid State Relay
Mount Type
PCB
Maximum Load Voltage
530V
Minimum Load Voltage
48V ac
Minimum Control Voltage
1V
Maximum Control Voltage
15V
Series
MCX
Terminal Type
Screw
On State Resistance
1000000000Ω
Minimum Operating Temperature
-40°C
Switching Function
Zero Cross
Maximum Operating Temperature
80°C
Height
26mm
Length
43.1mm
Standards/Approvals
RoHS, UL E116949
Off State Leakage Current
0.1mArms
Capacitance
10pF
Output Type
SCR
Detalji o proizvodu
UL
Snížení sníží maximální zatěžovací proud při teplotách nad 25 °C.
Informacije o stanju skladišta trenutno nisu dostupne.
RSD 4.940
RSD 4.940 Each (bez PDV-a)
RSD 5.928
RSD 5.928 Each (s PDV-om)
1
RSD 4.940
RSD 4.940 Each (bez PDV-a)
RSD 5.928
RSD 5.928 Each (s PDV-om)
Informacije o stanju skladišta trenutno nisu dostupne.
1
| količina | Jedinična cena |
|---|---|
| 1 - 24 | RSD 4.940 |
| 25 - 99 | RSD 4.409 |
| 100+ | RSD 4.183 |
