TDK-Lambda DRB Switched Mode DIN Rail Power Supply, 85 → 264V ac ac Input, 24V dc dc Output, 1.25A Output, 30W
Tehnička dokumentacija
Tehnički podaci
Brand
TDK-LambdaSeries
DRB
Type
Switched Mode
Electrical Phase
1
AC or DC Input Voltage
ac
Input Voltage
85 → 264V ac
AC or DC Output Voltage
dc
Output Voltage
24V dc
Output Current
1.25A
Power Rating
30W
Number of Outputs
1
Dimensions
21 x 75 x 95mm
Height
75mm
Width
75mm
Depth
90mm
Minimum Temperature
-20°C
Ripple And Noise
40mV
Mounting Type
DIN Rail Mount
Load Regulation
240mV
Maximum Temperature
+70°C
Zemlja podrijetla
Malaysia
Detalji o proizvodu
DRB Series DIN Rail Power Supplies
The DRB series of DIN Rail power supplies offers basic functionality for power applications up to 480 W.
With a simple and economic design, the DRB series combines low cost and compact dimensions with efficiencies of up to 92%.
Informacije o stanju skladišta trenutno nisu dostupne.
Proverite ponovno kasnije.
RSD 7.707
Each (bez PDV-a)
RSD 9.249
Each (s PDV-om)
1
RSD 7.707
Each (bez PDV-a)
RSD 9.249
Each (s PDV-om)
1
Kupujte na veliko
| količina | Jedinična cena |
|---|---|
| 1 - 9 | RSD 7.707 |
| 10 - 14 | RSD 7.512 |
| 15+ | RSD 7.446 |
